262 GM 4.3L

Engine Specifications & Materials

• Type: 90 Degree 4.3 V6

• Displacement: 262 cubic inches (4294 cc)

• Compression Ratio: 9.4:1

• Valve Configuration: Overhead/Pushrod Actuated

• Valve Lifters: Hydraulic Roller

• Bore x Stroke: 4.00 x 3.48 in (101.60 x 88.39 mm)

• Main Bearing Caps: 2-Bolt

• Balance Method: External

• Intake Manifold: Two-Barrel

• Firing Order: 1-6-5-4-3-2
